Motherboard Tsis Siv Neeg Kho Tshuab
Dinghua's DH-A5 tag nrho tsis siv neeg kho qhov muag kho qhov muag BGA rework chaw nres tsheb ntiav servo motion control system, ua kom muaj kev tswj hwm peb hom: soldering, tso, thiab tshem tawm. Nws ruaj khov, txhim khu kev qha, nyab xeeb, thiab ua haujlwm tau zoo, ua kom tsis muaj zog ua haujlwm.
Hauj lwm lawm
Khoom Parameters
|
Tag Nrho Lub Zog |
6800W |
|
Lub tshuab cua sov sab saum toj |
1200W |
|
Hauv qab rhaub |
Qhov thib ob qhov kub thiab txias yog 1200W, thiab qhov thib peb qhov kub yog 2700W. |
|
zog |
AC220V ± 10% 50/60Hz |
|
Qhov ntev |
L650 × W700 × H850 hli |
|
Qhov chaw |
V-puab qhov, PCB bracket tuaj yeem hloov kho hauv X lossis Y kev taw qhia thiab nruab nrog universal clamp. |
|
Kev tswj qhov kub thiab txias |
K-hom thermocouple (K Sensor) Kaw lub voj voog tswj |
|
Temp raug |
± 1 degree |
|
PCB loj |
Max 500 × 450 mm Min 10 × 10 mm |
|
Workbench zoo -tuning |
± 15mm pem hauv ntej thiab nraub qaum, ± 15mm sab laug thiab sab xis |
|
Lub koob yees duab magnification |
10 x-100 x x |
|
BGA chip |
2 X 2-80 X 80 mm |
|
Yam tsawg kawg ntawm nti sib nrug |
0.1 hli |
|
Sab nraud Temperature Sensor |
5 个, Scalable (yeem) |
|
Qhov tseeb qhov chaw |
± 0.01 hli |
|
Net nyhav |
92kg ua |
| Ntsiab nta | bga optical alignment system, tsis siv neeg bga rework chaw nres tsheb, infrared bga rework chaw nres tsheb |
Product Description
1. Integrated Control System
Qhov no bga optical alignment system embedded industrial computer nrog HD touchscreen HMI thiab PLC tswj txhawb lub sij hawm ntawm qhov kub thiab txias nkhaus zaub, tsom xam, kho, thiab ntau-kho saib xyuas. Tus password tiv thaiv kev pib thiab kho qhov nkhaus kom ruaj ntseg ua haujlwm.
2. Precision Temperature Control
High-precision K-hom thermocouple kaw-voj PID tswj nrog nws pib-them nyiaj pab tswj kub hauv ± 2 degree. Sab nraud calibration interface tso cai rau cov ntaub ntawv pov thawj tseeb thiab hloov kho.
3. Automated Motion & Positioning
Servo-driven XYZ axes nrog V-groove thiab linear slide positioning pab ceev, zoo-kho PCB tuav rau ntau yam layouts thiab ntau thiab tsawg.
4. Fixturing yooj yim
Universal movable clamp tiv thaiv PCB npoo los ntawm kev puas tsuaj thiab deformation, sib xws nrog ntau BGA pob qhov ntev.
5. Cov Nozzles hloov tau
360 degree-rotatable titanium alloy nozzles hauv ntau qhov ntau thiab tsawg tso cai rau kev teeb tsa sai thiab hloov pauv.
6. Ntau qhov cua sov
Peb tus kheej tswj cov cua sov thaj tsam (sab saum toj / hauv qab) nrog kho qhov kub thiab txias, lub sijhawm, txoj kab nqes, cua txias, thiab lub tshuab nqus tsev ntawm HMI.
7. Programmable Profiles
Txog li 8-nqaj qhov kub thiab txias ntawm ib cheeb tsam, nrog rau kev khaws cia dav dav thiab touchscreen-raws li kev kho, tshuaj xyuas, thiab rov qab rau ntau hom BGA.
8. Visual Alignment System
High-precision digital video dlhos nrog joystick-tswj lub lens txav ua kom muaj kev tshuaj xyuas tag nrho ntawm BGA cov fab thiab qhov chaw, tshem tawm qhov muag tsis pom kev.
9. Ceev ceev
High-power cross-flow kiv cua txias txias PCB tom qab soldering los tiv thaiv warping.
10. Lub suab ceeb toom
Lub suab ceeb toom ua ntej 5-10 vib nas this ua ntej ua tiav cov txheej txheem qhia tus neeg teb xov tooj npaj txhij.
11. Auto-Cooling Protection
Lub tshuab cua txias ua haujlwm tom qab cua sov nres thiab kaw ntawm chav tsev kub kom tiv thaiv cov cuab yeej overheating thiab aging.
12. Tag Nrho Kev Ua Haujlwm Zoo
Integrated BGA pick-and-place system enables ntse, hands-free ua hauj lwm rau kev txhim kho efficiency.
13. Kev Nyab Xeeb & Ntawv Pov Thawj
CE-raws li kev tiv thaiv thaum muaj xwm txheej ceev thiab pib-tawm fais fab kev tiv thaiv kev tiv thaiv kev sib tsoo.
Cov duab ntxaws
Qhov no tsis siv neeg bga rework chaw nres tsheb ua haujlwm ib qho kev pabcuam PID meej, nws taug qab thiab saib xyuas ntawm tus nqi ntawm 20 milliseconds ib lub voj voog, muab cov lus qhia tiag tiag - lub sijhawm qhia rau qhov tseeb qhov kub thiab txias dua, qhov yuam kev me me, thiab ruaj khov dua!
Lub preheating cheeb tsam ntawm infrared bga rework chaw nres tsheb siv infrared LEDs, uas ua kom muaj cua sov ceev, ruaj khov kub tswj, ib puag ncig tus phooj ywg, kev siv hluav taws xob zoo, thiab qhov zoo nkauj zoo nkauj, thiab lub neej ntev.
Nrog laser positioning, PCB loading yog ceev thiab raug nyob rau hauv ib kauj ruam xwb.
Optical positioning xyuas kom meej nti mounting kev sib raug zoo.
Adaptable positioning system rau qhov yooj yim tso ntawm PCBs ntawm tag nrho cov duab thiab ntau thiab tsawg.
