Bga Smd Rework Chaw nres tsheb
DH-5880 BGA rework chaw nres tsheb: Laser liab dot kev taw qhia rau ib qho -kab motherboard tso. Adjustable maj mam airflow (loj rau cov chips) boosts efficiency & tiv thaiv me me - nti tawm. High- brightness shadowless LEDs ua kom pom tseeb qhov kev kuaj xyuas. CE- tau ntawv pov thawj, nrog nres thaum muaj xwm ceev thiab pib lub hwj chim tawm (ua rau qhov kub tsis ua haujlwm).
Hauj lwm lawm
Khoom nta:
1. High- brightness LED shadowless illumination ua rau nws yooj yim rau pom faulty motherboard chips;
2. Adjustable kiv cua ceev raws li nti loj, ua rework ntau npaum thiab tiv thaiv me me chips los ntawm cua tshuab thaum lub sij hawm soldering;
3. Laser liab dot kev taw qhia rau ib qho -kab motherboard tso;
4. Sab nraud USB interface rau importing thiab khaws cia ntau yam ntaub ntawv rework rau lub computer;
5. Nruab nrog lub tshuab nqus tsev twj tso kua mis yooj yim dua;
6. Plaub qhov ntsuas kub sab nraud cuam tshuam rau kev ntsuas kub kom raug ntau dua;
7. Touchscreen ua haujlwm nrog ua - hauv kev ua haujlwm ntse ntse, tiag - lub sijhawm tso saib thiab tsis siv neeg tshuaj xyuas cov ntaub ntawv rov ua haujlwm, tig koj mus rau hauv cov kws tshaj lij hauv vib nas this;
8. Muaj feem xyuam rau ntau hom chip rework (POP, SOP, SOJ, QFP, QFN, BGA, PLCC, SCP, thiab lwm yam)
Technical Parameters:
| Tag Nrho Lub Zog: | 5200W |
| Sab saum toj rhaub: | 1200W |
| Hauv qab rhaub: | Qhov thib ob cua sov cheeb tsam yog 1200W, thiab qhov thib peb cua sov cheeb tsam yog 2700W |
| Lub zog: | AC220V ± 10% 50Hz |
| Qhov Loj: | L500 × W600 × H700 hli |
| Qhov chaw: | Laser positioning nrog V-zoo li tus qhov, thiab nruab nrog universal clamp. |
| Kev tswj qhov kub thiab txias: | K-hom thermocouple (K sensor), kaw- voj tswj |
| Temp raug: | ± 2 degrees |
| PCB loj: | Max 420 × 370 hli Min 10 × 10mm |
| BGA Chip: | 2 X 2-80 X 80 mm |
| Yam tsawg kawg nkaus chip spacing: | 0.15 hli |
| Sab nraud Temperature Sensor: | Plaub, expandable (yeem) |
| Net nyhav: | 48kg ua |
| Daim ntawv thov: | bga tshuab rau laptop, bga rework khoom, cua kub bga rework chaw nres tsheb |
Khoom Description
1.This bga rework khoom embedded industrial tswj lub computer nrog lub siab - txhais touchscreen HMI. Cov cua kub cua sov, lub sij hawm, txoj kab nqes, cua txias thiab lub tshuab nqus tsev yog tag nrho cov teeb tsa ntawm HMI, uas qhia cov teeb thiab tiag - lub sij hawm kub curs ib txhij. Nws kuj tseem muaj qhov ntsuas qhov nkhaus tam sim los ua qhov tseeb - lub sijhawm ntsuas nkhaus thiab kho.
2.Peb thaj chaw cua sov ywj siab (saum toj & qis). Ob qho tib si sab sauv thiab sab qis txhawb 8-ntu qhov ntsuas kub, thiab txhua cheeb tsam tau txais kev ywj pheej PID algorithm rau kev tswj cua sov, kom ntseeg tau tias thaj chaw sib txawv synchronously ua tiav cov txiaj ntsig zoo. Qhov loj tshaj preheating cheeb tsam enables uniform PCB preheating yam tsis muaj deformation.
3.Stores txog 9999 txheej kub nkhaus kom ceev retrieve raws li sib txawv BGA Cheebtsam. Curve tsom xam, teeb tsa thiab kho yog txhua yam ua haujlwm ntawm lub vijtsam kov. Ob qhov kev sib txuas lus Suav thiab Askiv yog muaj rau kev cuam tshuam - ua haujlwm dawb los ntawm cov neeg siv khoom hauv tsev thiab txawv teb chaws.
4.High-precision K-hom thermocouple kaw- voj tswj thiab tsis siv neeg qhov kub thiab txias them nyiaj system paub txog qhov kub thiab txias qhov sib txawv ntawm ± 2 degree. Ib qho kev ntsuas kub sab nraud ua rau pom qhov ntsuas kub kom meej, nrog rau kev tsom xam kom raug thiab ntsuas qhov tseeb ntawm -lub sijhawm ntsuas kub.
5.PCB positioning txais V-zoo li tus grooves, ua ke nrog laser liab dot positioning coj ceev PCB kev sib raug zoo. Qhov hloov tau yooj yim thiab txav tau thoob ntiaj teb kev sib tw tiv thaiv PCBs los ntawm ntug kev puas tsuaj thiab deformation, thiab haum rau qhov chaw rau PCBs ntawm ntau qhov ntau thiab tsawg.
6.Dual lo lus zais tiv thaiv tiv thaiv arbitrary hloov kho los yog yuam kev tshem tawm cov kev pab cuam thiab tsis, xa superior kev ruaj ntseg kev tiv thaiv.
Lub tshuab bga no rau lub laptop nruab nrog cov nozzles hauv ntau qhov tshwj xeeb. Lub nozzles tuaj yeem tig thiab tso 360℃dawb, tso cai rau kev txhim kho thiab hloov tau yooj yim.
7.Lub tshuab cua txias ua haujlwm tau txais tom qab cov cua kub cua kub sab saud thiab qis qis. Lub siab-hloov hluav taws xob hla- ntxuam ntws nrawm nrawm rau PCBs kom tsis txhob deformation. Lub kaw lus txias kaw cia li kaw thaum qhov kub thiab txias poob rau hauv chav tsev kub, tiv thaiv kev laus ntawm lub tshuab los ntawm cov hluav taws kub seem thiab ua kom muaj kev pab cuam lub neej ntev.
8.Ua-hauv lub tshuab nqus tsev twj tso kua mis tshem tawm qhov xav tau rau qhov chaw cua sab nraud; cov cua kub bga rework chaw nres tsheb tuaj yeem siv tau nyob txhua qhov chaw los ntawm tsuas yog ntsaws rau hauv lub hwj huam mov, tsis pub dawb los ntawm huab cua txwv. Lub tshuab nqus tsev sab nraud yog muab rau kev yooj yim thiab ceev tuav ntawm BGA chips.
9.A USB interface muaj rau rub tawm qhov ntsuas kub tam sim no mus rau USB flash drive rau kev khaws cia, thiab txhawb nqa kev sib txuas ntawm nas kom txuas ntxiv lub neej kev pab cuam ntawm lub touchscreen.
10.Features lub suab -tswj ua ntej tswb muaj nuj nqi. Nws ceeb toom rau cov neeg ua haujlwm ntawm lub suab ceeb toom 5-10 vib nas this ua ntej ua tiav ntawm desoldering lossis soldering rau ua ntej - kev npaj ua haujlwm.
11.CE- ntawv pov thawj. Nws tau nruab nrog qhov hloov pauv thaum muaj xwm txheej ceev thiab lub zog tsis siv neeg- tawm kev tiv thaiv rau qhov xwm txheej tsis tau xav txog, thiab Circuit Court yuav txiav tawm hluav taws xob txiav txim siab thaum tswj qhov kub thiab txias.
