X-ray Smd Component Counter

Cov cuab yeej siv no yog siv los suav cov naj npawb ntawm cov khoom siv saum npoo av (SMDs) ntawm cov ntawv luam tawm Circuit Board (PCBs) sai thiab raug, uas txuag lub sijhawm thiab txo qhov kev pheej hmoo ntawm kev ua yuam kev.

Xa kev nug

Hauj lwm lawm

Cov khoom nta

SMD reel counter x ray yog tias nws ua haujlwm rau kev sim tsis muaj kev puas tsuaj. Nws tsis puascov khoom hauv txhua txoj kev,

uas xyuas kom meej tias lawv tseem siv tau tom qab suav. Tsis tas li ntawd, smd reel counter x rayyog ib qho yooj yim mus use thiab ua

tsis xav tau kev cob qhia tshwj xeeb los ua haujlwm.

X ray SMD tivthaiv txee lub npe hu ua smt reel x ray txee, ib yam nkaus, uas yog lub neej-saving rau cov tuam txhab uas xav tau.

suav ntau txhiab yam ntawm ib teev. Nws tshem tawmqhov xav tau ntawm phau ntawv suav, uas yog siv sijhawm ntev thiab nquag

ua yuam kev. Los ntawm automating txheej txheem suav, manufacturers tuaj yeemnce efficiency thiab productivity, uas thaum kawg ua

kom txuag tau nyiaj.

Tsis tas li ntawd, smt reel x ray txee yog ib qho cuab yeej zoo heev rau kev tswj kom zoo. Nws muab cov ntaub ntawv raug thiab txhim khu kev qha, uas tuaj yeem ua tau

siv los txheeb xyuas cov khoom puas thiab txhim kho cov txheej txheem ntau lawm. Qhov no yuav pab kom ntseeg tau tias cov khoom kawg yog siab

zoothiab ua tau raws li cov neeg siv khoom xav tau.

Cov khoom parameter

Fais fab mov	AC110 ~ 220V 10A +/{4}}%	Rated zog	1.7 KW TSI
Kev tshuaj xyuas hom	off-line	Kev tswj hwm txoj cai	tus password
Qhov rooj qhib	Manual + system induction	Txoj kev thauj khoom	Tib neeg
Lub teeb raj hom	kaw hom	Lub teeb lub cev voltage	50 ~ 90 KV
Lub teeb lub raj tam sim no	200ɥA	focal chaw loj	5 ua um
Geometry magnification	200 x	txias-down method	Forced cua txias
Khoom siv lub tais loj	7"-17"tab	Khoom lub tais thickness	Tsawg dua los yog sib npaug li 88mm
Radiation kam rau ua	10000 Gy	Kev tiv thaiv qib	l65 ua
suav ceev	7", hais txog 6-8s/4 reel	Load lub rooj loj	400 × 400mm / 10KG

Cov khoom tseem ceeb

Lub hauv paus ntsiab lus ua haujlwm ntawm X-ray SMD Component Counter feem ntau yog siv X-rays kom pom los ntawm SMD cov khoom kom tau txais cov duab

ntawm cov khoom. Tom qab ntawd, los ntawm cov duab ua tshuab, cov duab, qhov loj me, txoj hauj lwm thiab lwm yam ntaub ntawv ntawm cov khoom

raug txheeb xyuas thiab suav.

Tshwj xeeb tshaj yog, X-ray SMD Component Counter siv qhov chaw X-ray kom tso tawm X-rays, dhau los ntawm SMD tivthaiv los kuaj xyuas,

thiab tom qab ntawd hloov cov duab ntawm cov khoom siv rau hauv cov teeb liab digital los ntawm cov duab intensifier thiab CCD lub koob yees duab. Cov teeb liab digital no yog

tom qab ntawd xa mus rau cov duab ua haujlwm rau kev tshuaj xyuas ntxiv thiab ua tiav.

Hauv kev ua cov duab, cov duab yog thawj zaug ua ntej, suav nrog kev denoising, kev sib piv thiab lwm yam haujlwm rau

txhim kho cov duab zoo. Tom qab ntawd, los ntawm kev rho tawm cov yeeb yaj kiab thiab cov duab kos duab, cov duab, qhov loj me, txoj hauj lwm thiab lwm yam

cov ntaub ntawv ntawm cov khoom raug txheeb xyuas thiab suav. Thaum kawg, kev txheeb xyuas thiab suav cov txiaj ntsig yog cov khoom siv los ntawm kev tsim khoom

cov thawj coj.

Qhov zoo ntawm X-ray SMD Component Counter yog nws txoj kev tshawb nrhiav tsis sib cuag, uas tuaj yeem tshawb xyuas tus lej sai thiab raug.

thiab qhov chaw ntawm SMD Cheebtsam, zam qhov tsis raug thiab cov teeb meem kev ua haujlwm tsawg ntawm cov txheej txheem kev tshawb nrhiav ib txwm muaj. Tib lub sijhawm,

Cov cuab yeej tseem tuaj yeem kuaj xyuas thiab suav SMD cov khoom sib txawv ntawm ntau hom thiab cov lus qhia tshwj xeeb, nrog kev ua haujlwm siab thiab siv tau.

Tsis tas li ntawd, X-ray SMD Component Counter kuj tseem tuaj yeem ua ke nrog cov kab ntau lawm kom ua tiav kev tshawb pom thiab

suav, ntxiv kev txhim kho ntau lawm efficiency thiab zoo tswj theem.

xray counter machine

Cov khoom siv

Lub smt reel x ray txee yog ib qho cuab yeej siv X-ray tshuab rau kev tsis sib cuag thiab kev tshuaj xyuas.

Nws yog tsuas yog siv nyob rau hauv electronics manufacturing kev lag luam. Nws tuaj yeem paub txog kev txheeb xyuas tsis siv neeg, nrhiav pom thiab xaj,

sai thiab ua kom tiav cov kev txiav txim kom raug, txhim kho kev txiav txim kom zoo, txuag nqi zog, thiab txhim kho kev txiav txim kom zoo.

Hauv kev lag luam automotive, X-ray SMD xaj tshuab tuaj yeem siv los ua haujlwm, txheeb xyuas thiab xaj tsheb hluav taws xob.

cov khoom. Lawv tuaj yeem txiav txim qhov chaw ntawm ntau yam duab thiab qhov ntau thiab tsawg, txhim kho kev tsim khoom ntawm cov khoom siv

automotive kev lag luam. Nyob rau tib lub sijhawm, nws tseem tuaj yeem kuaj xyuas qhov ntau thiab qhov zoo ntawm cov khoom siv hluav taws xob hauv tsheb

Cheebtsam thiab ua kom meej thiab txhim khu kev qha tswj raws li cov neeg siv khoom xav tau, yog li txhim kho cov khoom zoo

hauv kev lag luam automotive.

Tsis tas li ntawd, X-ray SMD dispensing tshuab kuj muaj kev ntseeg siab thiab raug, uas tuaj yeem ua tau raws li qhov tseeb

thiab kev ruaj ntseg cov cai ntawm kev lag luam automotive. Nws tseem tuaj yeem ua tiav kev txiav txim sai ntawm ntau qhov chaw raws li

cov neeg siv khoom xav tau, txuag lub sijhawm thiab chaw ntau dua, thiab muab kev pabcuam rau kev lag luam tsheb ua haujlwm tau zoo dua.

x-ray smd component counter x ray part counter

Nyob rau hauv luv luv, X-ray SMD dispensing tshuab yog dav siv nyob rau hauv electronics manufacturing kev lag luam thiab tuaj yeem pab cov tuam txhab txhim kho.

cov khoom zoo thiab kev ntseeg siab, txo qis tus nqi thiab cov nqi rov ua dua.
