Xray Rau Electronics Voard
Qhov no PCB X-ray tshuab xa cov khoom tsis zoo -kev ntsuas kev puas tsuaj rau hluav taws xob thiab kev tsim khoom. Raws li ntau yam kev lag luam X-ray tshuab, nws muaj lub ntsej muag tilting detector thiab programmable theem rau ntau- lub kaum sab xis soj ntsuam-zoo tagnrho rau tsheb ECU tester daim ntawv thov thiab PCB sib dhos tsom xam.
Hauj lwm lawm
Product Overview
Peb lub xeev- ntawm--artPCB X-ray tshuabredefines precision non{0}}kev kuaj kev puas tsuaj. Raws li ntau yamIndustrial X-ray tshuab, nws muab cov peev xwm tsis sib xws rau kev tswj xyuas zoo thiab tsis ua hauj lwm tsom xam thoob plaws cov khoom siv hluav taws xob thiab cov khoom siv.
Core Features & Advantages
1.XY-Axis Motion Stage:Ua kom muaj kev soj ntsuam dav dav, txhim kho kev tshuaj xyuas cov khoom dhau los thiab kev ntseeg siab.
2.60℃Tilting duab ntes:Ua kom yooj yim rau kev soj ntsuam ntawm sab- phab ntsa tsis xws luag hauv cov khoom xws li BGAs, kom paub meejECU tester-qib tsom xam rau cov khoom siv hluav taws xob tseem ceeb hauv tsheb.
3.Real-Lub Sijhawm Kab Kab Ntsig Taub Hau & Txais:Siv lub siab -rhiab heev Japanese HAMAMATSU kaw qhov chaw ua ke nrog lub siab -txhais lus digital flat- vaj huam sib luag ntes kom nkig, tiag - lub sijhawm duab.
4.Visual Automated Navigation Qhov rai:Tus neeg siv- tus phooj ywg interface tso cai rau cov neeg ua haujlwm nrhiav sai thiab zoom rau hauv cov hom phiaj tshuaj xyuas, ua kom cov haujlwm ua haujlwm zoo.
5.Spacious Loading Platform:Features loj 550mm x 670mm soj ntsuam chamber, haum rau ntau yam khoom ntau thiab tsawg.
6.Programmable Inspection Recipes:Qhov zoo tshaj plaws rau siab - ntim automated soj ntsuam, boosting efficiency thiab xyuas kom meej cov qhabnias batch tom qab batch.
7.Digital Work Library Management:Txuag, hloov kho, thiab tswj cov kev tshuaj ntsuam xyuas kom rov ua tau zoo dua thiab tshawb xyuas qhov zoo.
8.S/ERP System Integration:Txhawb customizable connectivity rau seamless cov ntaub ntawv tswj thiab kev koom ua ke rau hauv ntse Hoobkas systems.
Daim ntawv thov Domains
Qhov hwm noIndustrial X-ray tshuabyog engineered rau kev ua tau zoo nyob rau hauv ntau yam sectors:
1.Semiconductor & Advanced Ntim:IC, BGA, CSP, Flip Chip tshuaj xyuas.
2.PCB & Sib dhos (SMT / DIP):Kev davPCB X-ray tshuabrau solder pob qij txha, voids, thiab cov khoom muab tso rau.
3.Automotive Electronics:Kev soj ntsuam tseem ceeb rauECU testerkev siv, sensors, connectors, thiab tswj modules.
4.Automotive Parts:Aluminium castings, moldings, thiab lwm yam kev nyab xeeb -cov khoom tseem ceeb.
5. Tshiab Zog:Roj teeb cell & module tshuaj xyuas rau lithium{0}}ion roj teeb.
6.Specialized Industries:Photovoltaic cells, molded plastics, ceramic substrates, thiab lwm yam.
Khoom Parameters
Tshuab Specifications :
| Yam khoom | Parameter | Yam khoom | Parameter | |
| Dimension: | 1500 × 1500 × 2100mm | Fais fab mov: | AC220V 10A | |
| Qhov hnyav: | kwv yees 1500KG | Ntim hnyav: | Kwv yees li . 1800KG | |
| Pob qhov ntev: | 1600 × 1600 × 2200mm | Kev siv zog: | 1.7 KW TSI | |
| Loading method: | phau ntawv | Kev kuaj xyuas hom: | offline | |
| Txoj kev ua haujlwm: | phau ntawv | Kev tswj hwm kev tso cai: | tus password |
X-ray tube:
| Yam khoom | Parameter | Yam khoom | Parameter |
| Lub teeb yeeb nkab hom: | kaw | Phototube tam sim no: | 200μA |
| Lub teeb lub cev voltage: | 90kv ua | Focus loj: | 3-5 hli |
| Txoj kev ua kom txias: | cua txias | Geometric magnification: | 300x ib |
Kev ntsuas qhov system:
| Yam khoom | Parameter | Yam khoom | Parameter |
| Ntes: | New TFT | Radiation kam rau ua: | 10000 Gy |
| Siv tau zoo imaging cheeb tsam: | 130 × 130 hli | Kev tiv thaiv qib: | IP65 |
| Pixel matrix: | 1536 × 1536 | Loj: | 176 × 176 × 47mm |
| Pixel loj: | 85μm | Qhov hnyav: | 3.5 KG |
| Spatial daws teeb meem: | 5.8 hli / hli | Lub zog: | 9W |
| Ncej tus nqi: | 20fps ua | Ua haujlwm kub: | 10-40 degree |
| AD conversion tus lej: | 16bit ib | Cia kub: | -10-55 ° C |
| Cov ntaub ntawv interface: | Gigabit Ethernet | Ua haujlwm humidity: | 20-90% HP (tsis muaj condensation) |
| Trigger hom: | nruam nrhiav tau, mem tes synchronization | Cia humidity: | 10-90% HP (tsis muaj condensation) |
| X-ray zog ntau yam: | 40KV-130KV TSI | Duab Chaw: | Brightness, Contrast, Auto Gain thiab Exposure |
Muaj PC
| Yam khoom | Parameter | Yam khoom | Parameter |
| Saib xyuas: | 21.5-inch high-txhais saib | Kev khiav hauj lwm System: | Windows 10 64-ib |
| Cov lus qhia ua haujlwm: | Keyboard/Ntaus | Hard drive / Nco: | 1 TB/8G |
Kev ruaj ntseg lav
Radiation Dose:
Siv cov hlau- txhuas- steel tiv thaiv qauv, nrog rau pem hauv ntej lub qhov rooj saib qhov rais ua los ntawm cov hlau lead- muaj iav rau hluav taws xob tiv thaiv. Ntawm txhua txoj hauj lwm 20mm los ntawm qhov chaw kaw, qhov ntsuas hluav taws xob ntsuas qhov sib npaug tsawg dua lossis sib npaug li 1 μSv / h, ua raws li cov qauv thoob ntiaj teb.
Lead Glass Saib Qhov rai:
Pob tshab txhuas iav cais tawm hluav taws xob thaum tso cai rau kev soj ntsuam cov khoom kuaj.
Kev ruaj ntseg Interlock:
Txhua lub qhov rooj saib xyuas tau nruab nrog ob lub siab - qhov hloov pauv hloov siab. Thaum twg lub qhov rooj qhib, X-ray raj yog tam sim ntawd thiab txiav tawm ntawm-energized.
Electromagnetic Safety Qhov Rooj Hloov:
Lub qhov rais saib yog haum nrog lub tshuab hluav taws xob hluav taws xob uas tiv thaiv lub qhov rais qhib thaum lub X-ray raj ua haujlwm.
Emergency Stop Button:
Nyob ib sab ntawm tus neeg teb xov tooj txoj haujlwm; nias nws tam sim ntawd txiav tawm lub hwj chim.
Saib Qhov rai:
Nta lub qhov rais pom pob tshab, tso cai rau saib ncaj qha ntawm tus qauv thaum ua haujlwm.
X-ray Tube Protection:
X-ray raj yuav tsum raug kaw ua ntej tawm hauv software interface los ua lwm yam haujlwm.
Tshawb pom cov duab
Xaiv peb qhov system tsis yog ib qhoPCB X-ray tshuab, tab sis ua tiavIndustrial X-ray tshuabecosystem tsim los ua kom tau raws li qhov xav tau nruj ntawm kev tsim khoom niaj hnub thiab kev ruaj ntseg zoo, tshwj xeeb tshaj yog rau cov qib siabECU testervalidation thiab tshaj.
