Xray Pcb Tshuaj Xyuas Tshuab
Qhov no siab heev PCB X-Ray Inspection Tshuab DH-X9 yog tsim los kom xa cov kev tswj xyuas zoo rau cov khoom siv hluav taws xob niaj hnub no. Nws seamlessly ua ke siab - kev daws teeb meem duab nrog ntse automation los xyuas kom meej qhov tsis xws luag xws li BGA voids thiab solder txuas nrog qhov tsis sib xws.
Hauj lwm lawm
Khoom Taw Qhia
Precision Unveiled: Lub Advanced PCB X-Ray Inspection Tshuab rau Kev Tswj Xyuas Zoo
Nyob rau hauv lub ntiaj teb zoo sib xws ntawm kev tsim khoom siv hluav taws xob, pom tsis yog kev ntseeg xwb - nws yog qhov tseeb. Qhov tsis xws luag muab zais los ntawm qhov muag liab qab, xws li BGA voids, solder bridging, los yog tsis txaus los ntawm - qhov sau, tuaj yeem cuam tshuam kev ncaj ncees ntawm tag nrho lub rooj sib txoos. Peb lub xeev - ntawm --artPCB X-Ray Inspection Tshuabyog engineered los nthuav qhia cov zais qhov tsis zoo nrog qhov tsis pom tseeb thiab kev ua haujlwm zoo, hloov koj cov txheej txheem kev lees paub zoo los ntawm kev twv ua haujlwm rau hauv kev lees paub qhov tseeb.
Technical Specifications & Nyob rau hauv -Qhov tob nta
1. Superior Motion & Imaging System rau kev ua kom tiav
PebPCB Xray tshuabyog tsim los ntawm lub platform tag nrho motorized tsim rau kev nkag siab tshaj plaws. Qhov loj - txoj kab uas hla (530mm) theem muab qhov chaw txaus rau cov vaj huam sib luag loj. Nws qhov tseeb XY txav thiab tag nrho 360℃kev sib hloov kom ntseeg tau tias txhua qhov sib koom ua ke tuaj yeem coj mus rau qhov chaw ntawm qhov chaw soj ntsuam. Tseem ceeb heev, tus duab ntes tus 60-degree tilting muaj peev xwm tso cai rau kev soj ntsuam sab-lub kaum sab xis ntawm kev sib txuas ntsug, ua rau nws zoo heev rau kev txheeb xyuasBGA soldering tsis xws luag (piv txwv li, lub taub hau-hauv- hauv ncoo, voids) thiab los ntawm - qhov pin soldering teeb meemuas pom tsis pom los ntawm sab saum toj - saib.
2. Siab -Stability Core Imaging Cheebtsam
Hauv plawv ntawm lub kaw lus yog kaw microfocus X-ray qhov chaw. Qhov kev kaw no -tube tsim muaj npe nrov rau nws lub neej ua haujlwm ntev thiab kev ua haujlwm ruaj khov, tshem tawm qhov xav tau ntawm kev saib xyuas niaj hnub xws li cov roj hloov uas xav tau los ntawm cov laus qhib - raj tshuab. Nws ua hauj lwm nyob rau hauv tandem nrog ib tug siab - daws teeb meem cov vaj huam sib luag ca vaj huam sib luag ntes kom xa ntse, tiag- cov duab lub sij hawm nrog zoo sib xws, tso cai rau koj los mus txiav txim cov ntsiab lus feeb me me li ob peb microns.
3. Intelligent Software rau txhim kho cov khoom tsim tau
Visual Navigation & Automated Programming: Lub software intuitive interface nta lub qhov rais saib xyuas navigational. Tsuas yog nyem rau ntawm qhov chaw, thiab theem tau txav mus rau ntawd. Koj tuaj yeem tsim, txuag, thiab kho cov kauj ruam-los ntawm- kauj ruam tshuaj xyuas cov kev pab cuam rau ntau hom pawg thawj coj saib, ua kom muaj kev tshuaj ntsuam xyuas tag nrho.
Comprehensive Digital Management & Integration: Txhua qhov kev tshuaj ntsuam xyuas thiab nws qhov sib thooj X- cov duab hluav taws xob tau khaws cia rau hauv "Rework Digital Library" tsim kom muaj kev taug qab thiab rov qab tau yooj yim. Lub kaw lus txhawb kev cai kev koom ua ke nrog lub HoobkasMWS (Manufacturing Execution Systems) thiab ERP platforms, tso cai rau cov ntaub ntawv ntsuas ntws ncaj qha rau hauv koj cov kev tswj hwm kev tsim khoom.
4. Engineered rau ntau hom kev lag luam
Qhov kev tshuaj xyuas ntau yam no yog qhov zoo tagnrho rau ntau yam kev siv tshaj li tus qauv PCBAs:
Automotive Electronics: Tshawb xyuas kev nyab xeeb -ECU modules tseem ceeb thiab kev sib txuas ntom ntom.
Aerospace & Kws muaj txuj ci: Txheeb xyuas qhov kev ncaj ncees ntawm siab - kev ntseeg tau sib dhos.
LED kev tsim khoom: Tshawb xyuas cov kev pab cuam nyob rau hauv loj LED chips ntawm txhuas substrate boards.
Fais fab Electronics: Txheeb xyuas cov thermal ncoo voids thiab busbar soldering nyob rau hauv lub hwj chim modules.
Visual Guide to Key Features (Conceptual Illustration)
| Feature | Kev piav qhia | Visual Benefit |
|---|---|---|
| Multi-Axis Stage & Tilting Ntes | Daim duab qhia txog PCB tig 360℃ntawm XY theem thaum lub ntsuas ntsuas caj npab tig mus rau 60 degree. | Ua kom pom lub peev xwm los tshuaj xyuas ib qho kev sib koom tes ntawm txhua lub kaum sab xis, tshem tawm qhov muag tsis pom kev. |
| High -Kev daws teeb meem duab | Ib sab-los ntawm- sab kev sib piv: qhov muag plooj X- duab tshav nrig piv rau cov duab zoo nkauj los ntawm peb lub cev, qhia meej meej cov pob BGA thiab qhov tsis xws luag. | Highlights qhov tshwj xeeb cov duab clarity uas ua rau muaj tseeb tsis xws luag. |
| Automated Program Workflow |
Ib qho screenshot ua ntu zus ntawm software: 1) Loading board layout, 2) Kev txheeb xyuas cov ntsiab lus, 3) Ua haujlwm tsis siv neeg scan, 4) Qhia cov ntsiab lus nrog NG cov cim. |
Piav qhia txoj hauv kev los ntawm kev teeb tsa mus rau automated, ceeb toom - tsav kev tshuaj xyuas. |
Cov duab piv txwv
Vim li cas thiaj xaiv Peb PCB X-Ray Inspection Solution?
Cov txheej txheem no yog ntau tshaj li ib qho kev tshuaj ntsuam xyuas; nws yog ib qho cuab yeej cuab tam rau koj cov kab ntau lawm. Nws ua yeeb yamtxo tus nqi khiav tawmntawm latent defects,txo cov nqi rov ua haujlwm dua thiab ua haujlwm tsis tiav, thiab muabirrefutable txheej txheem pov thawjrau kev ua raws cai thiab kev tshuaj xyuas cov neeg siv khoom. Los ntawm automating qhov tseem ceeb tshaj plaws thiab rov ua dua ntawm kev tswj kom zoo, nws tso koj cov kws tshaj lij los tsom mus rau kev tsom xam thiab kev txhim kho cov txheej txheem, ua rau kev ua haujlwm zoo tshaj plaws.
Kev nqis peev hauv qhov tseeb. Txhawb koj qhov kev tsim khoom nrog kev pom tseeb.
Peb lub tuam txhab
Shenzhen Dinghua Technology Co., Ltd. yog lub teb chaws siab -tech enterprise integrating R&D, ntau lawm, muag thiab kev pab cuam ntawmX-ray suav tshuab, X-ray NDT tshuab, BGA rework chaw nres tsheb, thiab cov khoom siv automation! Peb muaj lub zog tiag tiag los muab koj cov khoom zoo tshaj -, cov kev pabcuam zoo meej thiab kev txhawb nqa kev tshaj lij.
Pom nyob rau xyoo 2011, Dinghua Technology tau tsom mus rau R&D thiab tsim cov X-RAY suav tshuab, X-ray NDT cov cav tov, BGA rework chaw nres tsheb, thiab cov khoom siv hluav taws xob ntau lawm. Lub tuam txhab siv "kev tshawb fawb thiab kev tsim kho raws li lub hauv paus, zoo li lub hauv paus, thiab kev pabcuam raws li qhov lav" thiab tau cog lus los tsim "cov cuab yeej tshaj lij, kev ua haujlwm zoo, thiab kev pabcuam tshaj lij"! Nyob rau tib lub sijhawm, lub tuam txhab ua raws li kev tsim kho lub tswv yim ntawm "kev tshaj lij, kev ncaj ncees, kev tsim kho tshiab, thiab pragmatism" thiab tau tsim ib pab pawg kws tshaj lij kev tshawb fawb thiab kev tsim kho. Nws niaj hnub nqus thiab rub tawm ntawm kev tsim kho kev lag luam hauv tsev thiab txawv teb chaws, ua siab loj tshawb nrhiav, qhia cov tswv yim tshiab, thiab paub txog kev hloov pauv los ntawm cov khoom siv kho vajtse ua ke rau kev koom ua ke. Kev hloov pauv thib ob hauv kev tswj hwm kev lag luam, dhau los ua tus thawj coj thiab tus thawj coj hauv X-ray suav lossis NDT, BGA rework chaw nres tsheb, thiab cov khoom siv hluav taws xob tsim khoom lag luam.
