PCB Xray tshuab
Dinghua PCB Xray tshuab DH-X7 yog qhov siab- qhov kev ntsuas qhov tseeb siv los tshuaj xyuas cov qauv sab hauv ntawm cov khoom siv hluav taws xob thiab cov khoom sib dhos yam tsis muaj kev puas tsuaj. Nws siv X-ray imaging thev naus laus zis txhawm rau nkag mus rau cov ntaub ntawv thiab tsim cov duab ntxaws ntxaws, tso cai rau cov neeg ua haujlwm pom cov teeb meem zais zais uas pom tsis pom ntawm qhov muag liab qab.
Hauj lwm lawm
Khoom Description
Dinghua PCB Xray tshuab DH-X7 yog lub siab- precision automated X-ray tshuaj xyuas tshuab siv los tshuaj xyuas cov qauv sab hauv ntawm cov khoom siv hluav taws xob thiab cov khoom sib dhos yam tsis muaj kev puas tsuaj. Nws siv X-ray imaging thev naus laus zis txhawm rau nkag mus rau cov ntaub ntawv thiab tsim cov duab ntxaws ntxaws, tso cai rau cov neeg ua haujlwm pom qhov tsis xws luag uas tsis pom ntawm qhov muag liab qab.
Cov khoom specification
|
Tag nrho lub tshuab xwm txheej
|
||||
|
Dimension
|
1100 * 1200 * 2100 hli
|
|
Fais fab mov
|
AC220V 10A
|
|
Qhov hnyav
|
Kwv yees li 1200 kg
|
Qhov hnyav tag nrho
|
Txog 1300 kg
|
|
|
Ntim
|
1300 * 1400 * 2200 hli
|
Rated zog
|
1000w
|
|
|
Qhib txoj kev
|
Kev tuav tes
|
Kev tshuaj xyuas
|
Tawm - kab
|
|
|
Uploading
|
Labor
|
Kev tso cai
|
Tus password
|
|
|
Xray cev
|
||||
|
Hom
|
Muab kaw
|
|
Tam sim no
|
200 ua
|
|
Qhov hluav taws xob
|
90kv ua
|
Focal chaw loj
|
5 ua um
|
|
|
Txias
|
Cua
|
Geometry magnification
|
300 x
|
|
|
Kev lag luam computer
|
||||
|
Zaub
|
24-nti HD saib
|
|
Kev ua haujlwm system
|
Windows10 64bits
|
|
Txoj kev ua haujlwm
|
kryboard/mus
|
Hard disk / nco
|
1 TB/8G
|
|
Cov khoom siv
Lub peev xwm tshuaj xyuas ntawm SMT X-cov khoom siv hluav taws xob soj ntsuam:
1. Advanced Semiconductor & Component Level Tshuaj ntsuam xyuas
Tshaj li qhov pom tau yooj yim, SMT X- cov khoom siv hluav taws xob soj ntsuam yog qhov tseem ceeb rau kev txheeb xyuas cov qauv kev ncaj ncees nyob rau hauv siab -cov khoom ntom ntom.
BGA, CSP, thiab Flip-Chip:Kev soj ntsuam kom ntxaws ntawm cov pob solder txoj kab uas hla, ncig, thiab kev tso kawm. Tshawb xyuas "Lub taub hau-hauv-Phillow" (HiP) qhov tsis xws luag thiab kev txuas sab hauv.
QFN/QFP thiab Fine-Pitch Leads:Kev tshuaj xyuas ntawm "ntiv taw" thiab "pob luj" fillets thiab kuaj xyuas qhov sib tsoo ntawm lub cev.
Wafer -Theem Ntim (WLP):Kev txheeb xyuas ntawm micro- cracks, TSV (Los ntawm -Silicon Via) kev ncaj ncees, thiab kev puas tsuaj.
Tuag Txuas & Encapsulation:Kev ntsuas qhov sib xws ntawm epoxy / nplaum txheej thiab kuaj pom kev delamination lossis cua npuas hauv TPU thiab yas encapsulations.
2. Electromechanical & Passive Component Analysis
X-ray tso cai rau kev tshuaj xyuas sab hauv "dig muag" nta uas kho qhov muag tsis tuaj yeem ncav cuag.
Sensors & MEMS:Txheeb xyuas qhov sib txawv ntawm cov diaphragms sab hauv, cov khoom txav, thiab micro- daim iav tsis ua txhaum lub foob hermetic.
Capacitor thiab Resistor:Txheeb xyuas cov txheej txheem dielectric sab hauv, kev sib dhos electrode, thiab kev txiav txim siab ncaj ncees hauv MLCCs.
Fuses & Heater Wires:Kev tshuaj xyuas qhov txuas ntxiv thiab ntsuas ntawm cov ntsiab lus sab hauv los tiv thaiv "qhib Circuit Court" ua tsis tiav hauv kev tswj hwm thermal.
Optical Fiber & Kev Tshawb Fawb:Xyuas kom meej meej cov tub ntxhais kawm sib dhos thiab kuaj xyuas micro-cov pob txha hauv cov cladding lossis connector ferrules.
3. Siab -Kev Sib Txuas Sib Txuas & Vuam
X-ray yog tus qauv kub rau tsis yog- kuaj kev puas tsuaj (NDT) ntawm cov hlau-rau- hlau bonds.
Hlau Weldments & Solder Joints:Ntsuas qhov tob tob, porosity, thiab cov qauv fusion hauv cov pob qij txha tseem ceeb.
Hlau Bonding:Tshawb xyuas "cheb" (deformation ntawm kub / txhuas hlau) thaum lub sij hawm molding txheej txheem thiab xyuas cov ntaub ntawv sib cuag.
Probe & Connector Pins:Tshawb xyuas tus pin deformation, plating thickness sib xws, thiab zaum qhov tob hauv siab -cov khoom sib txuas.
4. Zoo Tswj & Traceability nta
Niaj hnub nimno AXI (Automated X-Ray Inspection) systems integrates data processing with imaging.
Volumetric Voiding Calculation:Automated suav ntawm voiding feem pua tiv thaiv IPC cov qauv kom ntseeg tau tias thermal thiab hluav taws xob conductivity.
Dimensional Metrology (hlau qhov siab):Precise Z-axis ntsuas rau qhov siab tivthaiv, solder paste ntim, thiab lub dab dej kub standoff.
Automated Traceability (QR / Barcode):Integrated scanners txuas X-ray soj ntsuam cov duab ncaj qha mus rau tus lej xov tooj ntawm PCBA rau 100% cov ntaub ntawv traceability.
Cov khoom ntim
1, Standard Export Ntoo rooj plaub;
2, Kev xa khoom hauv 2 hnub ua haujlwm tom qab them nyiaj paub meej;
3, Kev xaiv xa khoom ceev suav nrog FedEx, DHL, UPS thiab lwm yam, lossis los ntawm huab cua lossis hiav txwv;
4, Chaw thau khoom chaw nres nkoj: Shenzhen lossis Hongkong.
Yog tias koj muaj lus nug ntxiv lossis xav tau kev pab, thov tsis txhob yig tiv tauj peb. Peb yuav zoo siab pab koj!
