Kub Cua BGA Re-work chaw nres tsheb kho

1.infrared cua sov system2.powerful crow flow fan3.sound hint system4.laser positioning

Xa kev nug

Hauj lwm lawm

Macbook Cpu kho cov cuab yeej DH-A2E

Lub tshuab cua kub BGA rework chaw nres tsheb yog ib qho khoom siv los kho pob kab sib chaws (BGA) cov khoom ntawm cov ntawv luam tawm.

Circuit Board (PCBs). Qhov chaw nres tsheb muaj cov cua sov uas siv cov cua kub kom yaj lub solder uas twb muaj lawm ntawm lub

BGA tivthaiv, ua kom yooj yim tshem tawm ntawm PCB. Cov cua kub BGA rework chaw nres tsheb kuj siv tau rau qhov chaw

ib qho tshiab BGA tivthaiv rau PCB los ntawm reflowing lub solder siv lub cua sov.

A2E Assemble

Specifications:

1	Tag nrho lub zog	5200w
2	3 lub tshuab hluav taws xob ywj pheej	Sab saum toj kub cua 1200w, qis cua kub 1200w, hauv qab infrared preheating 2700w
3	Qhov hluav taws xob	AC220V ± 10% 50/60Hz
4	Hluav taws xob qhov chaw	7 '' kov npo + siab precision ntse temp tswj module + stepper tsav tsav + PLC + LCD zaub + siab daws teeb meem optical CCD system + laser positioning
5	Kev tswj qhov kub thiab txias	K-Sensor kaw-voj + PID tsis siv neeg temp them + temp module, temp raug nyob rau hauv ± 2 degree.
6	PCB positioning	V-groove + universal fixture + movable PCB txee
7	Muaj feem xyuam PCB loj	Max 370x410mm Min 22x22mm
8	Muaj feem xyuam BGA loj	2x2mm ~ 80x80mm
9	Qhov ntev	600x700x850mm (L * W * H)
10	Net nyhav	70 Kg

Daim ntawv thov:

Cov txheej txheem ntawm kev kho BGA tivthaiv siv lub cua kub BGA rework chaw nres tsheb muaj ob peb kauj ruam. Ua ntej,

cov solder uas twb muaj lawm ntawm BGA tivthaiv yog melted siv cua kub, tso cai rau cov khoom raug tshem tawm los ntawm

lub PCB. Qhov chaw nyob ib ncig ntawm BGA tivthaiv yog tom qab ntawd ntxuav kom tshem tawm cov khoom seem lossis cov khib nyiab.

Thaum lub cheeb tsam huv si, ib qho BGA tshiab tau muab tso rau hauv PCB, thiab cov khoom siv tau rov qab siv cov cua kub.

BGA rework chaw nres tsheb. Qhov kub thiab airflow ntawm cov cua sov yog ua tib zoo kho kom paub meej tias cov

solder yog melted tusyees thiab BGA tivthaiv yog nrees txuas rau PCB.

A2E 内部发热系统

Tsis Siv Neeg Soldering Robot System DH-A2E

DH-A2E yog tswj los ntawm tus neeg siv-phooj ywg touchscreen. Nws ergonomically tsim ntsuas vaj huam sib luag suav nrog

joystick tswj rau ob lub koob yees duab zoom thiab, thaum lub kaw lus nyob rau hauv phau ntawv hom, ntsug tswj ntawm lub tshuab cua sov sab saud

thiab tso lub taub hau.

Dial adjustments tswj tivthaiv thiab PCB teeb pom kev zoo raws li cov huab cua ntws los ntawm lub cua sov sab sauv, meej tswj ntawm

uas tuaj yeem tiv thaiv kev hloov ntawm cov chips me me thaum lub sij hawm reflow.

Lub chaw nres tsheb rework lub vaj huam sib luag kuj suav nrog K-hom thermocouple cov tswv yim thiab USB chaw nres nkoj rau xa tawm cov khoom siv.

kub profiles rau flash drive.

Product imga2

Zuag qhia tag nrho, cov cua kub BGA rework chaw nres tsheb yog ib qho cuab yeej tseem ceeb rau kev kho cov khoom siv hluav taws xob thiab tuaj yeem pab txuas ntxiv

lub neej ntev ntawm cov cuab yeej kim los ntawm kev tso cai rau cov khoom tsis raug hloov pauv es tsis txhob muab pov tseg tag nrho cov cuab yeej. automatic rework station 4
