Lub Dinghua X-Ray Tsis yog-Kev Ntsuas Ntsuas Kev Ntsuas DH-X8 nta lub kaw X- txoj kab hluav taws xob, lub siab-txhais lus digital ca vaj huam sib luag ntes, laser tsis siv neeg navigation thiab qhov chaw, thiab CNC nrhiav hom nrog X / Y / Z axis motion control. Nws kuj suav nrog 360-degree kev sib hloov ua haujlwm rau kev tshuaj xyuas ntau lub kaum ntse ntse, muab kev ua haujlwm yooj yim thiab nrawm txhawm rau nrhiav qhov tsis xws luag.

Xa kev nug

Hauj lwm lawm

Cov Khoom Zoo

1.Lub X-ray qhov chaw txais yuav X- txoj kab hluav taws xob kaw, muaj lub neej ntev, kev saib xyuas- ua haujlwm dawb, thiab 130KV voltage.

2.Tus tshiab - tiam siab -txhais lus digital flat-vaj huam sib luag xray tshuaj ntsuam xyuas, nrog siab - daws teeb meem tsim, xa cov duab zoo hauv lub sijhawm luv luv.

3.Laser tsis siv neeg navigation thiab positioning pab ceev xaiv ntawm txoj hauj lwm shooting.

4.X / Y / Z axis tswj kev ua haujlwm yooj yim.

5.CNC tshuaj xyuas hom kom ceev tsis siv neeg tshawb pom ntawm ntau-point arrays.

6. Tiltable lub kaum ntse ntse: ± 60 degree; multi-lub kaum ntse ntse soj ntsuam ua kom yooj yim rau kev kuaj xyuas qhov tsis xws luag.

7.Optional 360℃rotation muaj nuj nqi. X-ray tshuab rau pcb

8.Visualized siab- txhais lub qhov rais navigation rau kev ua haujlwm yooj yim thiab ceev qhov chaw ntawm lub hom phiaj tshuaj xyuas.

9. Lub tshuab kuaj xray muaj 550mm * 550mm loading theem.

10.Kev ua haujlwm yooj yim thiab ceev ceev tso cai rau kev txheeb xyuas cov hom phiaj tsis raug; cov neeg siv tuaj yeem pib tom qab 2 teev ntawm kev cob qhia.

Khoom Specifications

X-ray Source	Hom: Kaw lub hom phiaj microfocus Voltage: 40-130KV (kho tau) Tam sim no: 10-300uA Max zog: 39W Microfocus Loj: 5μm
Pav ca -Panel Detector	Hom: Amorphous silicon tiaj tus- vaj huam sib luag Pixel Matrix: 1536 × 1536 Qhov Loj: 130.56 × 130.56mm Spatial Resolution: Ntau dua lossis sib npaug li 5.5Lp / mm Pixel Pitch: 85μm
Chaw thau khoom theem	Loj: 550 × 550mm Kev soj ntsuam ntau: 500 × 500mm Max Load: 10kg Radiation Isolation: 5 hli tuab txhuas phaj
Chassis & Hluav taws xob	Qhov Loj: 1450 (L) × 1530 (W) × 2000 (H) mm Qhov hnyav: ~ 1500kg Fais fab mov: AC220 ± 10% 10A Tag nrho lub zog: 1500W
Kev Nyab Xeeb & Ib puag ncig	Kev khiav hauj lwm Env: 22 ± 3 degree, 50% RH ± 10% RH Radiation Kev Nyab Xeeb: Tsawg dua lossis sib npaug ntawm 1μSV / H (ua tau raws li cov qauv thoob ntiaj teb) Kev Tiv Thaiv Cov Ntsiab Lus: Kev sib cuam tshuam, hluav taws xob qhov rais xauv, nres thaum muaj xwm ceev
Qhov ntev	1450mm (L) × 1530mm (W) × 2000mm (H)
Qhov hnyav	Kwv yees li . 1500kg
Fais fab mov	AC220 ± 10% 10A
Tag Nrho Lub Zog	1500W
Temp & Humidity	22 ± 3 degree, 50% RH ± 10% RH
Kev tiv thaiv hluav taws xob	Steel- lead- steel qauv; leaded iav qhov raisDose npaum li cas tsawg dua los yog sib npaug rau 1μSV / H (ua tau raws li cov qauv thoob ntiaj teb)
Kev Tiv Thaiv Tseem Ceeb	1. Kev ruaj ntseg interlock (qhov rooj qhib → X-ray disabled) 2. Electromagnetic qhov rais xauv (X-ray ntawm → qhov rais xauv)3. Thaum muaj xwm ceev nres khawm (ib qho - nias lub hwj chim txiav)
Chaw tsim tshuaj paus	Shenzhen Dinghua Innovation Automation Co., Ltd.(X-RAY / BGA rework chaw nres tsheb tshwj xeeb)

Kev ruaj ntseg Interlock	3 siab - qhov hloov pauv hloov pauv hloov pauv tau nruab rau ntawm qhov chaw pem hauv ntej thiab nram qab. Thaum lub qhov rooj qhib, X-ray qhov chaw raug tiv thaiv thiab X-ray raj tsis tuaj yeem qhib tau.
Electromagnetic Safety Qhov Rooj	Lub qhov rais soj ntsuam yog nruab nrog ib tug electromagnetic hloov. Thaum X- txoj kab hluav taws xob ua haujlwm, lub qhov rai saib tsis tuaj yeem qhib.
Khawm Nres Ceev	Thaum muaj xwm txheej ceev, nias txiav tawm tam sim ntawd.

Software ua haujlwm

Muaj nuj nqi Module	Kev piav qhia
Txoj kev ua haujlwm	Tag nrho cov haujlwm ua tiav ntawm lub joystick + keyboard + nas (cov lus tsa suab tuaj yeem txav tau los ntawm kev rub tus nas; X-ray raj Z-axis tuaj yeem zoomed hauv / tawm ntawm rubey zawv zawg).
X-ray Tube Control	Nyem lub pob nrog tus nas kom tig X-ray on/off; tube voltage thiab tube tam sim no qhov tseem ceeb yog tso tawm nyob rau hauv lub sij hawm. Kev hloov kho tuaj yeem ua los ntawm cov nyees khawm nce / nqis, slider dragging, los yog phau ntawv tswv yim; lub raj fais fab thiab microfocus loj kuj tau tshwm sim hauv lub sijhawm.
Status Bar	Qhia qhov xwm txheej cuam tshuam, preheating xwm txheej, thiab X-ray on/off xwm txheej los ntawm liab/ntsuab flashing teeb.

Qeb	Yam khoom	Kev piav qhia
(General Functions)	Kev kho duab nyhuv	Kho cov duab lub lim theem, ci ntsa iab, sib piv, thiab lim kom ua tiav cov duab xav tau.
	Qhov rai navigation	Tom qab lub koob yees duab siab -txhais xim lub koob yees duab ntes cov duab hauv lub platform, nyem rau txhua txoj haujlwm ntawm daim duab kom sai nrhiav lub hom phiaj tshuaj xyuas.
	Motion Axis Status	Qhia qhov tseeb - lub sijhawm sib koom ua ke thiab tus lej loj.
	Kev tshuaj ntsuam xyuas	Sequentially qhia txhua qhov kev ntsuas (void rate, nrug, cheeb tsam, thiab lwm yam khoom ntsuas).
	Tswj ceev	Kho cov axis txav ceev (qeeb, ib txwm, ceev) ntawm qhov chaw bar thiab software.
Void Rate Measurement	Tsis siv neeg suav	Ntsuas voids hauv cov khoom ntim khoom (xws li BGA, QFN); cia li suav BGA qhov tsis muaj feem cuam tshuam hauv cheeb tsam xaiv. Teem cov theem pib kom txiav txim siab qhov tsis muaj dab tsi thiab qhov siab tshaj plaws void.
	Kev Kho Parameter	Kho qhov chaw pib, qhov loj me, Blob hom, thiab kev suav cov lej kom tau txais cov txiaj ntsig tsis siv neeg suav.
Dimension xam	Los ntawm -Hole Solder Ratio xam	Feem ntau yog siv los ntsuas qhov ntub dej ntawm los ntawm - qhov khoom; tau qhov kev faib ua feem thiab qhov siab ntawm cov khoom ntawm cov khoom siv los ntawm kev xaiv cov duab plaub.
	Kev ntsuas nrawm nrawm	Tau qhov kev ncua deb ntawm ob lub ntsiab lus ntawm arbitrary ncej xaiv.
	Point- Kab nrug	Tau qhov kev ncua deb ntawm ib tug taw tes thiab ib kab ntawm arbitrary point thiab kab xaiv.
	Lub kaum sab xis	Teem cov ntsiab lus A thiab B raws li lub hauv paus, tom qab ntawd nyem qhov C los ntsuas lub kaum sab xis ntawm cov kab hluav taws xob BA thiab BC.
	Lub voj voog	Feem ntau yog siv los ntsuas lub voj voog (piv txwv li, cov khoom siv solder); xaiv ib lub voj voog ntawm kev xaiv thav duab kom tau nws qhov ncig, thaj chaw, thiab lub vojvoog.
	Kab rov tav Rectangle	Feem ntau yog siv los ntsuas cov square Cheebtsam; xaiv ib square ntawm thav duab xaiv kom tau nws qhov ntev, dav, thiab cheeb tsam.

Tsis siv neeg soj ntsuam	Yam khoom	Kev piav qhia
	Kev tshuaj xyuas CNC	Rau ntau lub ntsiab lus tshuaj xyuas, tsuas yog teeb tsa txhua txoj haujlwm thiab ntsuas cov khoom; lub software yuav cia li ntes txhua qhov chaw soj ntsuam thiab txuag cov duab.
	Laser Positioning	Liab dot laser positioning ntaus ntawv, dual kev pab rau yooj yim navigation.
